4L60E Transmission Rebuild Page 4 of 33


Figure 7
Figure 7
Figure 8
Figure 8

Figure 7 and 8. The case and bellhousing are masked for primer and paint. All machined surfaces are covered so they do not get paint on them.

Figure 10
Figure 10
Figure 9
Figure 9

Figure 9. Primed and painted! The primer was VHT self-etching primer, and the paint was VHT Burnt Copper Engine Paint.

Figure 10. The copper will be the color of the jeep when the project is finished. Accents will be black.
