4L60E Transmission Rebuild Page 25 of 32


Figure 86
Figure 86
Figure 87
Figure 87

Figure 86. Push in the solenoid, and use a pick to pull the retaining clip out. Make sure you have your finger over the clip so it does not fly off. Ask how I know this. Pull the old solenoid out and put the new solenoid in. Reinstall the clip.

Figure 87. Hooked up the wiring harness. We are now ready for the oil pan.

Figure 89
Figure 89
Figure 88
Figure 88

Figure 88. The pan is installed. Torque the bolts to 120 inch lbs. The stainless bolts look very nice with the black pan. These bolts were purchased from Fastenal, way cheaper than getting them from an auto parts supplier. They are M8 x 16mm.

Figure 85. The servo assembly is next. The Sonnax Super Hold 2nd and 4th servos will be used for this.
